Yokogawa AAM10 Analog Input Module 4-20mA 1-5V N-IO System (Spares Stock)

Yokogawa AAM10 Analog Input Module 4-20mA 1-5V N-IO System

Brand: Yokogawa
Model: AAM10
Type: Analog Input Module

Description:
The Yokogawa AAM10 is a high-performance analog input module from the N-IO series, designed for industrial automation and process control systems. It supports both 4–20 mA current signals and 1–5 V voltage inputs, making it ideal for interfacing with 2-wire transmitters and standard instrumentation. Engineered for accuracy, reliability, and seamless integration within Yokogawa control systems.

Specifications:
Input Signal: 1–5 V DC / 4–20 mA DC
Input Resistance: 1 MΩ (Voltage), 250 Ω (Current)
Allowable Input: -10 to 30 V DC / ≤40 mA DC
Transmitter Supply: 25.0–25.5 V DC (Max 60 mA)
Accuracy: ±4 mV (Voltage), ±16 µA (Current)
Temperature Effect (per 10°C): ±8 mV / ±32 µA
Update Period: 50 ms
Current Consumption: ≤250 mA (5.0 V DC)
Signal Isolation: Input signals insulated from system
Withstand Voltage: 1500 V AC/min
Installation: I/O Module Nest
Wiring: Terminal connection with M4 screws

Package Includes:
1 × Yokogawa AAM10 Module
