SOFTWARE-HOUSE AS0073-CSI I8-Csi Eight Input Reader Bus ALARM (New In Box)

Software House I8-CSI Eight Input Reader Bus AS0073 – NEW IN BOX

Condition:
Brand New – Unused, unopened, undamaged item in its original packaging.

Brand: Software House (Tyco / Johnson Controls)
Model: I8-CSI
MPN: AS0073
Product Type: Input/Output Module
Category: Access Control / Alarm Monitoring

Description:
The Software House I8-CSI module is a powerful input expansion device designed to enhance the capabilities of iSTAR and apC door controllers. It supports numerous supervised circuit types and EOL resistance values, enabling compatibility with existing field wiring without requiring changes to end-of-line resistors.

Ideal for alarm monitoring, control, and elevator applications, the I8-CSI provides eight Class A supervised inputs with LED indicators to simplify commissioning and troubleshooting.

Features:

• Cost-effective expansion of input capacity

• Compatible with the full range of Software House iSTAR and apC controllers

• Locate modules up to 1,220 m (4,000 ft) from controllers over RS-485 RM bus

• Reduces sensor/control wiring length, saving installation costs

• I8-CSI supports more than 20 different supervised circuit types

• Three status LEDs per input (red/yellow/green) for quick diagnostics

• Dedicated tamper input on each module

• Small, modular size requires minimal panel space

• Optional UL-listed enclosure available

• Fully compatible with C•CURE 9000 and C•CURE 800/8000

Technical Details:

• Inputs: 8 × Class A supervised inputs

• Communication: RS-485 Reader Bus

• Distance: Up to 1,220 m (4,000 ft)

• Enclosure: Compact module, optional UL-rated housing

• Status Indication: 3 LEDs per input (R/Y/G)

• Dedicated tamper input

Logistics:

• HS Code: 85371099 (Programmable control/relay equipment ≤1000V, parts)

• Country of Origin: USA

• UPC: Not available

• Weight: approx. 0.45 kg (1 lb)

• Dimensions: approx. 120 × 80 × 35 mm
