OMRON DRT1-ID08 DeviceNet, 24 VDC, 10mA.

Omron DRT1-ID08 DeviceNet Remote I/O Module – 8-Point NPN Input, IP67

Enhance your industrial automation setup with the Omron DRT1-ID08 DeviceNet Remote I/O Module. Engineered for durability and precision, this unit is ideal for demanding environments where reliability is paramount.

🔧 Key Features

• Input Type: NPN (Sink) Transistor Inputs

• Number of Inputs: 8

• ON Voltage: 15 VDC minimum

• OFF Voltage: 5 VDC maximum

• Input Current: 6.0 mA max. per point at 24 VDC; 3.0 mA max. per point at 17 VDC

• OFF Current: 1.0 mA max. per point (at 24 VDC)

• ON Delay Time: 1.5 ms max.

• OFF Delay Time: 1.5 ms max.

• Number of Points per Common: 16

• Residual Voltage: 1.2 V max. (0.5 A between each output terminal and G)

• Leakage Current: 0.1 mA max.

• Protection Rating: IP67 – suitable for harsh environments

• Mounting: DIN Rail or Panel Mount

🌡 Environmental & Electrical

• Operating Temperature Range: –10 °C to +55 °C

• Storage Temperature Range: –25 °C to +65 °C

• Ambient Humidity: 25% to 85% (non-condensing)

• Power Supply Voltage: 24 VDC

• Current Consumption: 30 mA max. at 24 VDC

📐 Dimensions & Weight

• Weight: Approx. 185 g

📦 Brand Information

• Model: DRT1-ID08

• Brand: Omron

• Country of Manufacture: Japan

✅ Durable and sealed IP67 module designed for reliable performance in industrial environments.
