OMRON CRT1-OD16-1B CompoNet, 16 outputs, PNP, 0.5 A, 24 VDC, screw terminals

Omron CRT1-OD16-1B CompoNet Output Module – 16 PNP Outputs, 24 VDC, DIN Rail Mount

Enhance your industrial automation setup with the Omron CRT1-OD16-1B CompoNet Output Module. Engineered for durability and precision, this module is ideal for demanding environments where reliability is paramount.

🔧 Key Features

• Model: CRT1-OD16-1B

• Type: Digital Output Module

• Communication Interface: CompoNet Slave

• Number of Outputs: 16

• Output Type: PNP Transistor

• Rated Output Current: 0.5 A per output, 4 A per common

• Permitted Output Voltage: 0 to 26.4 VDC

• Residual Voltage: 1.2 V max. (0.5 A DC)

• Leakage Current: 0.1 mA max.

• ON Delay Time: 0.5 ms max.

• OFF Delay Time: 1.5 ms max.

• Isolation Method: Photocoupler

• Output Indicators: Yellow LED for each channel

• Mounting Style: DIN Rail Mounting

• Connection Method: Screw Terminal

• Protection Rating: IP20

🌡 Environmental & Electrical

• Operating Temperature Range: –10 °C to +55 °C

📐 Dimensions & Weight

• Size (W × H × D): 115 × 52 × 50 mm

• Weight: Approx. 141 g

📦 Brand Information

• Brand: Omron

• Country of Manufacture: Japan

✅ Compact and reliable output module for seamless integration into Omron CompoNet automation systems.
