OMRON CRT1-ID16-1B CompoNet, 16 x 24 VDC inputs, PNP, screw terminals

mron CRT1-ID16-1B Digital Input Module – 16-Channel PNP Inputs, CompoNet Communication, DIN Rail Mount

Enhance your industrial automation setup with the Omron CRT1-ID16-1B Digital Input Module. Engineered for durability and precision, this module is ideal for demanding environments where reliability is paramount.

🔧 Key Features

• Model: CRT1-ID16-1B

• Type: Digital Input Module

• Number of Inputs: 16 digital inputs

• Input Type: PNP

• Input Voltage Range: 0 to 26.4 VDC

• Input Current: 6 mA at 24 VDC

• ON Voltage: 15 VDC minimum

• OFF Voltage: 5 VDC maximum

• ON Delay: 1.5 ms maximum

• OFF Delay: 1.5 ms maximum

• Isolation Method: Photocoupler

• Indicators: Yellow LED for each input channel

• Communication Interface: CompoNet

• Mounting Style: DIN Rail Mounting

• Protection Rating: IP20

🌡 Environmental & Electrical

• Operating Temperature Range: 0 °C to +55 °C

• Storage Temperature Range: –20 °C to +65 °C

• Ambient Humidity: 25% to 85% (non-condensing)

• Power Supply Voltage: 14 to 26.4 VDC

• Current Consumption: 55 mA max. at 24 VDC

📐 Dimensions & Weight

• Size: 115 mm (W) × 52 mm (H) × 50 mm (D)

• Weight: Approx. 141 g

📦 Brand Information

• Brand: Omron

• Country of Manufacture: Japan
