NetComm Wireless NTC-140-02 4G M2M Router SMS IoT 2xGb Ports

Brand: NETCOMM WIRELESS
Model: NTC-140 (SKU NTC14002)
Description: 4G M2M industrial IoT router with dual 4G antennas, 2× Gigabit Ethernet (RJ45), Micro-USB 2.0 OTG (0.5 A), MicroSD slot, built-in GPS and ignition-sense input; Linux-based NetComm OS with SDK for edge apps; carrier-grade management via TR-069, LwM2M, SNMP and extensive SMS control; VPNs (IPsec up to 5 tunnels, OpenVPN client/server/P2P, GRE, PPTP), Modbus TCP/RTU/ASCII gateway, bridge/PPPoE, VRRP, DHCP server with advanced options; DIN-rail or wall mount; LEDs for power/service/signal; CE/RCM/E-Mark, RoHS, WEEE.
Cellular Bands: LTE B1/B3/B7/B8/B20; UMTS B1/B2/B5/B8; GSM 850/900/1800/1900.
Peak Data: LTE Cat 3 up to 100/50 Mbps (20 MHz), 50/25 Mbps (10 MHz); HSPA+ 42/5.76 Mbps; EDGE 236 kbps.
Connectivity & I/O: 2× 10/100/1000Base-T (Auto-MDIX); 1× multipurpose I/O pin; SIM tray (2FF, lockable) with optional soldered MFF2 eSIM.
Antenna Ports: 2× SMA (3G/4G) + 1× SMA (GPS).
GPS: Embedded receiver; active/passive antenna support; TTFF Cold 32 s/Warm 29 s/Hot 1 s; tracking sensitivity −161 dBm.
Power: 8–40 V DC via 4-way Molex Mini-Fit (min 6 W; recommend 12 V 1.5 A); dedicated ignition input; ISO7637 vehicle protection; optional AC adapter.
Operating Temperature: −40 °C to +85 °C (storage −40 °C to +85 °C).
Device Size & Weight: 143 mm (L) × 107 mm (W) × 34 mm (D); ~235 g.
Package (Shipping): 0.080 m (L) × 0.150 m (W) × 0.190 m (H); 0.700 kg; 0.00228 m³.
Inclusions: Router unit with DIN-rail bracket (as supplied by manufacturer).
Barcode (EAN): 9317773017397
Condition: New
Country of Origin: Not specified
HS Code: 8517.62.00
