Merlin-Gerin 18359 Multi 9 C120N C125 MCB 1P 125A C Curve 10kA (New)

The Merlin Gerin Multi 9 C120N C125 is a 1 pole miniature circuit breaker, reference 18359, from the Multi 9 range now sold by Schneider Electric. It provides overload and short circuit protection for a 125A circuit with a C tripping curve, which suits general power and lighting circuits with moderate inrush currents.

The breaker is rated 240/415V AC with a breaking capacity of 10kA and complies with IEC 60947-2 and IEC 60898. It clips onto 35mm DIN rail and takes 3 (27mm) modules of width. The unit is new old stock made in France and is supplied without a box. Three units are available; price is per breaker.

Specifications

Brand: Merlin Gerin (Schneider Electric)

Model: Multi 9 C120N C125

Part Number: 18359

Alternate Part Number: A9N18359 (Acti9 C120N 1P 125A C)

Product Type: Miniature circuit breaker

Poles: 1P

Rated Current: 125A

Tripping Curve: C

Rated Voltage: 240/415V AC

Breaking Capacity: 10kA

Standards: IEC 60947-2, IEC 60898

Mounting: 35mm DIN rail clip-on

Width: 3 (27mm) modules

EAN: 3303430183594

Country of Origin: France

Condition: New old stock, no box

Key Features

• C curve thermal magnetic protection
• Screw terminals top and bottom
• Trip-free mechanism with clear ON/OFF indication
• Clip-on DIN rail mounting
• Made in France

Typical Applications

• Distribution boards in commercial and industrial installations
• Replacement of an existing Multi 9 breaker of the same rating
• Machine and control panels

Package Includes

• 1 x Merlin Gerin 18359 C120N C125 circuit breaker

Additional Information

The breaker is supplied loose without retail packaging.

Installation must be carried out by a licensed electrician.

This was removed from an unused item and may show minor cosmetic marks from previous install.

Shipping from Sydney, Australia.
