Delta ESR-48/30D A Rectifier Module 48V 30A 54.3V Hot Swap (NEW In Box)

The Delta ESR-48/30D A is a plug in switch mode rectifier module for 48 volt telecom DC power systems. It slides into the front of a Delta rectifier shelf, converts mains AC to a regulated negative 48 volt DC output, and shares current with the other modules in the shelf so the plant can run N plus 1 redundant. Modules are hot swappable, so a faulty unit can be pulled and replaced without dropping the DC bus.

The carton on this unit reads Customer GFS, Customer model name ESR-48/30D A, Delta model name ESR-48/30D A, Default 54.3V, date code 0842, quantity 1, Made in China, RoHS5. The 54.3 volt figure is the factory default float voltage, which is the normal setting for a 48 volt lead acid string. Output is rated 30 amps, placing the module in the 1.6 to 1.8 kilowatt class. Cooling is by internal fan with speed control, and the input stage uses active power factor correction.

Specifications

Brand: Delta Electronics

Model: ESR-48/30D A

Part Number: ESR-48/30D A

Alternate Part Number: ESR-4830D

Product Type: Plug in switch mode telecom rectifier module

Nominal System Voltage: -48 V DC

Output Current: 30 A

Default Float Voltage: 54.3 V DC, as printed on the carton

Output Voltage Range: 38 to 60 V DC on this platform

Output Power Class: Approximately 1.6 to 1.8 kW

AC Input: 90 to 275 V AC operational on the platform, 45 to 65 Hz

Power Factor: Greater than 0.99 at 220 V AC full load, active PFC

Total Harmonic Distortion: Less than 5 percent

Efficiency: Greater than 90 percent at 220 V AC full load

Current Share: Less than 5 percent between modules

Hot Swap: Yes, front access

Cooling: Internal fan with speed control

Protection: Over voltage, over current and over temperature

Module Envelope: 132 mm H x 263 mm D x 83.6 mm W

Approximate Module Weight: 2.0 kg

Compliance: RoHS5

Serial Number: MA0842016667W0

Date Code: 0842

Country of Origin: China

Condition: New, in the original carton

Key Features

• 30 A output at a 54.3 V default float, ready to drop into a 48 V plant
• Hot swappable from the front, no need to drop the DC bus
• Active power factor correction above 0.99 with THD under 5 percent
• Current sharing within 5 percent for N plus 1 redundant operation
• Wide 90 to 275 V AC input tolerance on the platform
• New unused factory stock, not ex service

Typical Applications

• 48 V DC power plants at telecom, radio and network sites
• Adding capacity or redundancy to an existing Delta ES48 rectifier shelf
• Replacing a failed rectifier module in service
• Spares holding for sites running the Delta ESR platform

Package Includes

• 1 x Delta ESR-48/30D A rectifier module
• No rectifier shelf, controller, cabling or batteries are included

Additional Information

This is a plug in module and does not operate standalone. It requires a compatible Delta rectifier shelf from the ES48 family, together with the shelf controller. Please confirm your shelf accepts the ESR-48/30D form factor before ordering.

Delta does not publish a standalone datasheet for the ESR-48/30D A, so the electrical figures above are taken from Delta's own platform documentation for the shelf family this module belongs to. Some resellers headline this module as 1800 W. Thirty amps at 54.3 volts is 1629 watts, and Delta's published figure for the sibling ESR-48/30B is 1500 W, so we have quoted the class as approximately 1.6 to 1.8 kW rather than repeat an unverified number.

Do not confuse this with the ESR-48/40D D, a 40 amp CellD series module. A widely circulated PDF titled Delta ESR-48-30D D is in fact the datasheet for that different product.

This is legacy 2008 build stock. The ESR series is discontinued by Delta, whose current 48 V rectifier lines are the DPR EnergE series and the Eltek Flatpack families.

Installation must be carried out by a suitably qualified technician.

The item is new in the manufacturer's original packaging.
