Crestron TT-110-B-T Connect It Cable Caddy Black Textured No Outlet (New Opened)

The Crestron TT-110-B-T is a Connect It Cable Caddy in a black textured finish, Crestron part number 6506821. It is a flush tabletop connection compartment for conference and huddle rooms: it drops into a hole cut in the table, stores up to four presentation cables neatly below the table surface, and gives the presenter one-touch source switching through a connected Crestron control or DigitalMedia system.

This is the TT-110 variant, which has no AC outlet and no cables supplied. Two soft-touch capacitive buttons with multicolour LED indicators sit on the top face. Connections are a 4-pin Cresnet NET port, which carries both control and power, and a USB mini-AB port for connection to a DigitalMedia device. Power draw is just 1.2 W over Cresnet, 0.05 A at 24 VDC, with 5 VDC available via USB. The caddy fits a 102 mm hole saw cut into a table between 13 mm and 32 mm thick and is secured by a locking ring. It measures 120 mm in diameter, 150 mm across the locking ring, and 96 mm tall, weighing 433 g without cables. Operating range is 0 to 45 degrees C at 10 to 90 percent relative humidity, non-condensing. Crestron has discontinued this model.

Specifications

Brand: Crestron

Model: TT-110-B-T, Connect It Cable Caddy, black textured

Part Number: TT-110-B-T

Alternate Part Number: 6506821

Product Type: Flush tabletop cable caddy and connection compartment

Variant: No AC outlet, no cables supplied

Cable Capacity: Up to four customer-supplied presentation cables

Controls: 2 soft-touch capacitive buttons with multicolour LED indicators

Connections: 1 x 4-pin Cresnet NET port (control and power); 1 x USB mini-AB port for a DigitalMedia device

Power: 1.2 W via Cresnet, 0.05 A at 24 VDC; 5 VDC available via USB

Mounting: Flush tabletop, 102 mm hole saw, table thickness 13 mm to 32 mm, locking ring

Operating Conditions: 0 to 45 degrees C, 10 to 90 percent RH non-condensing

Dimensions: 120 mm diameter, 150 mm across the locking ring, 96 mm high

Weight: 433 g without cables

Country of Origin: Mexico

Condition: New, opened box

Key Features

• Presentation cables stay stored under the table rather than loose on it
• Two illuminated capacitive buttons for one-touch source switching
• Powered and controlled over a single Cresnet run
• Flush fit into a standard 102 mm hole with a locking ring
• Low profile textured black finish suits most conference tables

Typical Applications

• Boardroom and conference table cable management
• Huddle rooms and training rooms with BYOD presentation
• Retrofitting tidy cable storage into an existing Crestron room
• Lecterns and collaboration tables

Package Includes

• 1 x TT-110-B-T caddy unit
• 1 x black locking ring
• 1 x black cable plate
• 1 x 4-pin Cresnet connector
• 1 x 3/32 inch Allen wrench
• 4 x 6-32 x 1/4 inch Phillips pan-head screws
• 2 x USB cables, A to mini-B and B to mini-A, each approximately 2 m

This variant includes no AC outlet and no HDMI, VGA, audio or Ethernet presentation cables. Cresnet cable and a Crestron control or DigitalMedia system are not included.

Additional Information

Note that the T in this part number denotes a textured finish, not a Microsoft Teams variant. This model is discontinued by Crestron.

The item is new in the manufacturer's original packaging with the box opened. The photographs currently show the carton label only; further photographs of the unit will be added shortly. Package contents are listed from the Crestron TT-100 Series installation guide and have not been individually verified against this carton.

Shipping from Sydney, Australia.
