Crestron TS-770-B-S 7in Tabletop Touch Screen Black Smooth PoE+ (NEW Sealed)

The Crestron TS-770-B-S is a 7 inch tabletop touch screen in a black smooth finish, Crestron part number 6510820 and regulatory model M201923005. It sits on the meeting room table as the user interface for a Crestron control or AV system, and also runs Crestron Home OS, Zoom Rooms, Sonos control, scheduling apps and a web browser, with support for HTML5 and Crestron Smart Graphics.

The display is a 7 inch TFT active matrix colour LCD at 1280 x 800 in 16:10 WXGA, rated 350 nits with 850:1 contrast, 24-bit colour and edge lit LED backlighting with automatic brightness, viewable to plus or minus 80 degrees horizontally and vertically. Touch is projected capacitive with five point multitouch on edge to edge glass, and six programmable virtual buttons sit in a collapsible toolbar. Networking is 100BASE-TX on one RJ-45 PoE+ port plus 802.11a/b/g/n/ac Wi-Fi on 2.4 or 5 GHz to about 15 m, with a Crestron Bluetooth beacon. There is one USB 2.0 Type-A host port. A microphone and speakers are built in, supporting Rava SIP intercom and voice recognition, and the panel decodes H.265, H.264 and MJPEG streaming video up to 1920x1080 at 30 fps. Memory is 2 GB LPDDR3 and 16 GB eMMC. The unit is powered only over IEEE 802.3at Type 2 PoE+ and has an integral tilted base.

Specifications

Brand: Crestron

Model: TS-770-B-S, regulatory model M201923005

Part Number: TS-770-B-S

Alternate Part Number: 6510820

Product Type: Tabletop control and conferencing touch screen

Display: 7 in diagonal TFT active matrix colour LCD

Resolution: 1280 x 800, 16:10 WXGA, 24-bit colour

Brightness: 350 nits, 850:1 contrast, auto-brightness

Viewing Angle: Plus or minus 80 degrees horizontal and vertical

Touch: Projected capacitive, 5-point multitouch, edge to edge glass

Network: 1 x 8-pin RJ-45, 100BASE-TX with PoE+

Wireless: 802.11a/b/g/n/ac on 2.4 or 5 GHz, range to 15 m; WPA/WPA2-PSK TKIP and AES; Bluetooth beacon

USB: 1 x USB 2.0 Type-A host port

Audio: Built-in microphone and speakers, Rava SIP intercom, voice recognition

Streaming Video: H.265, H.264, MJPEG to 1920x1080 at 30 fps, up to 25 Mbps, RTSP

Memory: 2 GB LPDDR3 RAM, 16 GB eMMC, maximum project size 600 MB

Power: IEEE 802.3at Type 2 PoE+ only; 15 W requested with LLDP, 30 W without

Mounting: Free-standing tabletop with integral tilted base

Operating Conditions: 0 to 40 degrees C, 10 to 95 percent RH non-condensing

Dimensions: 175 mm W x 111 mm D x 102 mm H

Weight: 605 g

Country of Origin: Mexico

Condition: New, factory sealed

Key Features

• Single PoE+ cable delivers both power and network to the table
• Capacitive multitouch glass with a bright 1280 x 800 display
• Runs Crestron Home, Zoom Rooms and scheduling applications
• Wi-Fi as well as wired Ethernet for flexible table positioning
• Built-in microphone and speakers with Rava SIP intercom
• Streaming video decode for camera preview on the panel

Typical Applications

• Boardroom and meeting room table control
• Zoom Rooms and unified communications control surfaces
• Crestron Home residential control
• Lecture theatre and training room presenter positions

Package Includes

• 1 x Crestron TS-770-B-S touch screen in the sealed manufacturer carton

Crestron does not publish the carton contents for this model, and the box has not been opened, so accessories and cable lengths cannot be confirmed. A PoE+ switch or injector is not included.

Additional Information

The item is new in the manufacturer's original packaging. The carton is unopened and the factory tape is intact, so the photographs show the sealed box and its label rather than the unit itself.

Shipping from Sydney, Australia.
