Aritech TS1041 Tecom Challenger 8 Way Relay Board Expander (NEW In Box)

The Aritech TS1041 is an eight way relay board for the Tecom Challenger security system, sold in Australia under the Tecom part number S5020. It provides eight single pole Form C relays with dry NO or NC contacts, so panel outputs can drive door strikes, gates, lighting contactors, plant interlocks and any other equipment that needs a volt free contact. It supersedes the older TS0841 and offers lower latency, allowing more cards in series.

The board connects to its host by a ten way ribbon cable rather than a data bus, plugging into the Challenger panel at J14, a 4-Door or 4-Lift Controller at J21, a standard DGP at J8, or a Network Access Controller at J200. Cards can be daisy chained from an IN connector to an OUT connector. It runs from the 13.8 V DC supplied by the host, drawing 50 mA standby and 250 mA with all eight relays energised, and delays for several seconds on power up to prevent relay chatter.

Specifications

Brand: Aritech (Carrier)

Model: Tecom Challenger 8 Way Relay Board

Part Number: TS1041

Alternate Part Number: TECOM S5020

Product Type: Relay output expansion board, PCB only

Relays: 8 single pole Form C, NO or NC dry contacts

Contact Rating: 1 A at 0 to 30 V DC, 300 mA at 48 V DC

Operating Voltage: 13.8 V DC from the panel, DGP or auxiliary supply

Current Draw: 50 mA standby, 250 mA with all relays energised

Connection: 10 way ribbon cable. Challenger panel J14, 4-Door or 4-Lift Controller J21, standard DGP J8, Network Access Controller J200, or daisy chained card to card

Power Rule: Chains of 1 or 2 cards are powered from the parent device. Three or more cards require an external 12 V supply

System Maximums: Up to 32 to 64 cards per Challenger panel, 2 to 32 per 4-Door or 4-Lift Controller, maximum 2 per standard DGP. 512 physical relays and 64 controllers overall

Board Size: Tecom BB format, 176 x 52 mm

Compliance: RCM

Warranty Class On Label: 5 year

Serial Number: 276243060290

Country of Manufacture: China

Condition: New in box

Key Features

• Eight Form C dry contact relays in one card
• Daisy chains card to card for large relay counts
• Powered from the host panel or DGP for chains of one or two cards
• Power up delay prevents relay chatter
• Lower latency than the superseded TS0841
• Carries the Australian RCM mark

Typical Applications

• Driving door strikes, gates and boom gates from a Challenger panel
• Lighting and plant control interlocked with alarm areas
• Lift control outputs on a 4-Lift Controller
• Adding relay outputs to an existing Challenger installation

Package Includes

• One TS1041 relay PCB
• 8 x M3 x 10 screws and 6 x PCB standoffs
• 2 x two way and 8 x three way screw terminal plugs
• 1 x ring terminal
• 1 x ten way cable
• Installation sheet
• No enclosure and no power supply are included

Additional Information

Please read this before ordering. This is a Tecom Challenger part. It will not work in an Aritech ATS or Advisor Advanced panel, which is a different European system.

The card connects by ribbon cable, not RS-485, so it must be mounted inside or immediately adjacent to the host panel, DGP or door controller.

A maximum of two cards can be fitted to a standard DGP. Chains of three or more cards need their own 12 V supply.

Relay contacts are rated 1 A at 30 V DC. They are not suitable for switching mains voltage directly and interposing contactors should be used.

This is a bare PCB. No enclosure and no power supply are included. Installation should be carried out by a licensed security technician.

The carton shows shelf wear from storage. The contents are new and unused.

Shipping from Sydney, Australia.
