Aritech TS1021 Tecom Challenger10 8 Input Expander for TS1020 DGP (NEW In Box)

The Aritech TS1021 is an eight input expansion module for the Tecom Challenger10 TS1020 Analogue Data Gathering Panel, sold in Australia under the Tecom part number S5017A. It adds eight monitored alarm inputs to a DGP, and up to three modules can be daisy chained to take a single TS1020 from eight inputs to thirty two.

The module plugs into the DGP with a ten way ribbon cable at connectors J2 and J3, into the DGP's J7. It runs from the DGP's own 10.5 to 13.8 V DC supply and draws a maximum of 10 mA. A wide range of end of line resistor values is supported, including 10K, 6K8, 5K6, 4K7, 3K7, 3K3, 2K2, 2K2/6K8, 2K0, 1K5 and 1K0. It is a Tecom B size board and mounts on four standoffs inside the DGP enclosure.

Specifications

Brand: Aritech (Carrier)

Model: Tecom Challenger10 8 Input Expander

Part Number: TS1021

Alternate Part Number: TECOM S5017A

Product Type: Alarm input expansion module, PCB only

Inputs Added: 8 monitored alarm inputs

Host: Tecom Challenger10 TS1020 Analogue DGP only

Maximum Per DGP: 3 modules, taking the DGP from 8 to 32 inputs

Connection: 10 way ribbon cable, module J2 and J3 to DGP J7

Supply: 10.5 to 13.8 V DC from the DGP

Current Draw: 10 mA maximum

End Of Line Resistors Supported: 10K, 6K8, 5K6, 4K7, 3K7, 3K3, 2K2, 2K2/6K8, 2K0, 1K5, 1K0

Board Size: Tecom B size, mounts on 4 standoffs inside the DGP enclosure

Warranty Class On Label: 5 year

Serial Number: 260251690159

Country of Manufacture: China

Condition: New in box

Key Features

• Adds eight monitored alarm inputs to a TS1020 DGP
• Up to three modules take a DGP from 8 to 32 inputs
• Very low current draw at 10 mA maximum
• Wide range of end of line resistor values including 1K0, 1K5 and 2K0 which the older TS0021 does not support
• Ships with 18 x 10 kilohm end of line resistors
• Mounts inside the existing DGP enclosure

Typical Applications

• Expanding zone capacity on a Tecom Challenger10 installation
• Adding detection points to an existing DGP without a new enclosure
• Retrofitting additional reed switches, PIRs and duress buttons
• Spare or maintenance stock for a Challenger10 site

Package Includes

• One eight input expansion module with ten way cable
• 4 x three way plug on screw terminal connectors
• 5 x M3 x 10 mm pan head screws and 4 x PCB standoffs
• 1 x ring terminal
• 18 x 10 kilohm quarter watt resistors
• Installation sheet
• No enclosure and no power supply are included

Additional Information

Please read this before ordering. The TS1021 fits the Challenger10 series TS1020 Analogue DGP only. The superficially identical older TS0021 is the module that fits the TS1020, TS0820, TS0824 and TS0866. If you have a Challenger V8 era TS0820, TS0824 or TS0866 DGP you need the TS0021, not this board.

This is a ribbon cable module, not an RS-485 bus device, and it does not plug into a Challenger control panel directly. It expands a DGP.

A maximum of three modules can be fitted per DGP.

This is a Tecom Challenger part. It will not work in an Aritech ATS or Advisor Advanced panel.

This is a bare PCB. No enclosure and no power supply are included. Installation should be carried out by a licensed security technician.

The carton shows creasing and handling marks from storage. The contents are new and unused.

Shipping from Sydney, Australia.
